order(moq):
1 PCSPayment:
T/T, L/C, D/P, Western Unionproduct origin:
ChinaColor:
Yellow, Black or Customizedshipping port:
Xiamen，ChinaLead Time：
30 DaysRaw Material:
35MnBH35MnB Steel Master Link Bulldozer Lubricated Track Chain Assembly
1. Description
The quality and working life of oil links depends on the quality of raw steels, the hardness of rail surface, the depth of hardness layer, the quality of seal group etc.
2. Our Advantages
3. Basic Parameters
Material
35MnBH
Technique
Forging
Quality
HRC40-55
Warranty Time
12-18 months
Condition
New
Application
Bulldozer
4. Forging and Heat Treatment
5. Oil Link Structure
6. Main Dimensions of Installation
Main Parameters
|
Suitable Models |
Main Dimensions of Installation |
||||||||
|
P |
A |
B |
C |
E |
F |
H |
K |
L |
|
|
D20/D21 |
135 |
99 |
72 |
43.2 |
12.5 |
45 |
105 |
75 |
35 |
|
D30/D31 |
154 |
112.4 |
82.4 |
57 |
14.5 |
49.4 |
125.4 |
87 |
40 |
|
D3C |
155.6 |
104.7 |
88.9 |
54.8 |
14.5 |
60.5 |
128.5 |
88 |
39 |
|
D3/D3B/D4B |
155.6 |
104.7 |
88.9 |
54.8 |
14.5 |
60.5 |
128.5 |
88 |
39 |
|
D4/D4C |
171.45 |
108 |
108 |
60.3 |
15 |
70 |
144.8 |
95 |
44 |
|
D6/D6B |
171 |
144.5 |
125.4 |
58.7 |
16.5 |
90.4 |
173.4 |
101.6 |
42.8 |
|
D4D/D4E/941B |
171.45 |
108 |
108 |
60.3 |
16.5 |
68 |
144.8 |
95 |
44 |
|
TY100 |
175 |
158.4 |
122.4 |
57 |
16.5 |
84.6 |
173.2 |
101.5 |
45 |
|
D40/D45/D50/D53 |
175 |
158.4 |
122.4 |
57 |
18.5 |
84.6 |
173.2 |
101.5 |
45 |
|
D5/D5B |
175.5 |
144.5 |
125.4 |
58.7 |
16.5 |
90.6 |
172.6 |
103.2 |
43.5 |
|
SD13 |
190 |
160.4 |
124.4 |
62 |
20.5 |
85.6 |
176.4 |
105 |
47 |
|
D55/D57 |
190 |
160.4 |
124.4 |
62 |
20.5 |
85.6 |
175.6 |
105 |
47 |
|
D61 |
190 |
160.4 |
124.4 |
62 |
20.5 |
84.8 |
175.6 |
119 |
47 |
The models above are just for reference, we can't list all models here. We can supply more products as your requirements. Please feel free to send us your inquiry.
7. Why Choose YinTai?
We are a professional Excavator and Bulldozer spare parts manufacturer in China, we offer customized products that could meet your various needs. Follow us, we will exceed your expectation.
1. Our Factory View
2. Our Inspection Equipments
3. Our Main Certificates
4. Our Packing
We manufacture OEM and ODM track links. We are able to assure our track link has excellent wear resistance even in the most severe working conditions.
101 pitch track link assy, we have mature production processes to ensure our part has excellent wear resistance.
Track link assy is an important part for bulldozer undercarriage, driven by the sprocket and final drive, provides support for the machine weight, a rail for the machine to run on.
Track link is one part of undercarriage parts for crawler heavy equipments, such as excavator, bulldozer, crane, drilling machine etc.
Through our professional heat treatment, quenching and tempering, our track link could resist abrasion and impact well.
We manufacture OEM track link. Through our professional quenching and tempering, our products have goodcombination mechanical properties.
Our Track Link is adopting through hardening system and spraying quenching system while complying with the stringent ISO System.
OEM track link, we are using advanced machining center, horizontal and vertical CNC machining to execute manufacturing processes.
We are able to assure our track link has excellent wear resistance even in the most severe working conditions.
